Product Features
High reliability, high energy efficiency, high adaptability, and low lifetime cost.
Each unit undergoes strict operation testing before leaving the factory.
Precise water valve control and variable air volume control to adjust cooling capacity, air volume, and air pressure output based on cabinet temperature and air pressure conditions.
EVO control system ensures the best efficiency of the cooling system.
Efficient dehumidification design with absolute humidity control 100% front maintenance, saving floor space in the data center.
Various air supply modes available, including top air supply and bottom air supply.
Standard EC fans, with the bottom air supply unit using a sinking fan design for high efficiency and energy saving. The fan system saves over 30% energy compared to conventional air conditioning units and meets different external pressure requirements.
Modular design with a "V" or "A"-shaped large evaporator, high air volume, and high sensible heat ratio.
Efficient electrode humidifier with large humidification capacity, suitable for harsh water quality, low maintenance requirements, and easy disassembly for cleaning.
Full-color oversized touch screen in Chinese language.
Powerful EVO control system, capable of controlling multiple units and easily networking.
Group control modes: demand energy efficiency management, trend energy efficiency management, scheduled rotation, and automatic fault switching, achieving adaptive energy saving for air conditioning groups.
| Unit Return Air Condition: 24° C/50%RH |
| Model | TCMC526 | TCMC530 | TCMC535 | TCMC540 | TCMC546 | TCMC740 | TCMC746 | TCMC755 | TCMC765 | TCMC770 | TCMC780 | TCMC790 | TCMC799 |
| Main power | 3-phase 380Vac, 50Hz |
| Unit Performance Parameters |
| Overall Cooling Capacity (kW) | 26.8 | 30.9 | 35.9 | 40.3 | 46.9 | 40.7 | 47.6 | 55.6 | 65.8 | 71.6 | 80.2 | 92.6 | 100.2 |
| Sensible Capacity (kW) | 24.2 | 27.9 | 32.6 | 36.4 | 42.3 | 36.8 | 42.9 | 50.2 | 59.3 | 64.5 | 72.7 | 83.6 | 90.6 |
| Crew FLA-A | 28.3 | 31.3 | 38.7 | 41.2 | 48 | 43.6 | 48 | 51.3 | 58.5 | 62.9 | 69.3 | 82.5 | 84.3 |
| Quantity of Compressors | 1 | 2 |
| Indoor Fan Performance Parameters |
| Circulation air volume (m³/h) | 8000 | 9000 | 10000 | 11000 | 13000 | 11000 | 13000 | 14000 | 17000 | 18000 | 21500 | 23000 | 25000 |
| Quantity of Fans | 1 | 2 | 1 | 2 |
| Electric Heating Performance Parameters |
| Overall Heating Capacity (kW) | 6 | 9 |
| Humidifier Performance Parameters |
| Overall Humidity Capacity (kg/h) | 6 | 10 | 6 | 10 |
| Connecting Pipe Parameters |
| Air Pipe for Refrigerant (mm) | 16
Liquid Pipe for Refrigerant (mm) 22
Outlet Pipe for Condensate
Water (mm) 25
Inlet Pipe for Humidifier (only for
humidification) G1/2" |
| Liquid Pipe for Refrigerant (mm) | 22 |
| Outlet Pipe for Condensate Water (mm) | 25 |
Inlet Pipe for Humidifier (only for
humidification) | G1/2" |
| Unit Size and Weight |
| Unit Length (mm) | 1050 | 1050 | 1400 | 1400 | 1700 | 1400 | 1700 | 1700 | 2100 | 2100 | 2550 | 2550 | 2550 |
| Unit Depth (mm) | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 | 890 |
| Unit Height (mm) | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 | 1990 |
| Weight (kg) | 365 | 370 | 450 | 460 | 480 | 415 | 535 | 550 | 720 | 730 | 800 | 820 | 825 |
